5 Ton Europe Style European Single Girder Workshop Overhead
Traveling Bridge Crane
Description of European Type single girder overhead crane
Europe overhead crane advanced designed crane for the low headroom
and high lifting height demands. It has many advantages such as:
Strong rigidity, light dead weight, outstanding structure design,
long working lift etc. It could save your factory space and
investment effectively.
Its technology is advanced and design is based on international
standard: DIN (Germany),FEM (Europe), and ISO (International)
The all motions of this overhead crane are double speeds, the
lifting motor is double speed type,the cross travelling motor and
long travelling motor are controled by frequency inverte.
It could be widely used to handle materials in many industries'
workshop and warehouse,such as manufacture processing, warehouse,
storage, paper mill, electronics industries workshopand other
material handling situation
Crane capcity: 0.5ton-20ton
Crane span: 7.5m-35.5m
Crane lifting: 3m-37m
Working duty: A5
Control mothed: Wireless Remote
Technical parameter of European Type single girder overhead crane
| Model NO | HD |
| Condition | New |
| Type | Single Girder Crane |
| Load Capacity | 0.5t to 20t |
| Lifting height | 3 ~ 30 m or customized |
| Cross Speed | 0~30 M/Min (VVVF) |
| Working Class | A5-A8 |
| Origin | Henan, China |
| Working temperature | -20 ~ 40 ℃ |
| Way to Control | Pendant Push Button / Wireless Remote Controller / Cabin |
| Trademark | Silence CRANES |
| Specification | CE, ISO |
| HS Code | 8426112000 |
| Safety device | Buffer,current overload protection,overload device,power failure
protection |
| Application area | Factory,workshop,warehouse,power station,logstic,etc. |
Details description of European type single girder overhead crane
01 Hoist & Trolley: Compact structure,Light weight,Small wheel
load,Maximium space utilization and high cost effectiveness.
02 End Beam: High flexibility and reliability.
These compact,modular rail-mounted travel units can be connected
directly to crane girders and load bearing structures.
03 Crane Wheels: Strong wear and abrasion resistance,modular
design,compact structure,high degree of standardization and easy
assembling.
04 Crane Remote Control: Secure and dependable communications.
Advances synthesized RF controls with 62 user-programmable
channels,add flexibility to frequency management in the field.
Product Features of European Type single girder overehad crane
1). Single welding box girder
2). DIN/FEM standard deflection
3). Whole length CNC cutting for complete web plate, high
deflection accuracy
4). High quality automatic welding and NDT inspection
5). Shot-blasting Sa2.5 for complete girder after welding, stress
release
6). High tension bolts mounting between girder and legs, life time
safety connection
7). Compacted gear motor driving, stepless control, harden gear,
safety disc brake IP55
8). High protection class IP55, F class, 40% ED
9). Excellent driving properties, stepless control, smoothly moving
10). All hoist and crane movements are independent and can be run
simultaneously.
